LED 光源控制器系列
定電壓光源控制器
定電壓光源控制器
- AC 輸入(100V-240V)
- RS-232 或是Ethernet 版本可供選擇
- 良好的色溫穩定性
- 可以安裝Din Rail 及筆記型電腦
- 網頁設定功能僅Ethernet 版本具備
- 無須風扇冷卻
| Model | Lighting method | Drive method | light controlmethod | Intensity Adjustment | NO. of Channels | Applicable illumination(rating) |
Output Rated | Input voltage (rating) | Power consumption (Typ) |
|---|---|---|---|---|---|---|---|---|---|
| ILL-DP2454-2CR | Constant lighting | Constant Voltage system | 0~511 Step PWM intensityadjustment | - | 2 | 24V | 30WMax/CH Total 54W | AC 100V ~240Vac 50/60Hz | 65W(Typ) |
| ILL-DP2454-4CR | 4 |
