TCL-5M 物體側遠心鏡頭
TCL-5M 物體側遠心鏡頭
特色:
- 支援Pixel Size 3.45 µm及長達11mm對角線工業相機
- 高解析、高對比
- C-Mount
- 可支援5M的高解析相機
- 可彈性配合調整鏡頭以及客製需求
用途：
適用於高精度量測，如：SMT & PCB、LED、引擎零件、金屬零件應用等。
影像比較
5M 系列物體側遠心鏡頭具有高對比度及高質量影像
| 產品型號 | 倍率 | WD(mm) | 解析度 (µm) | N . A . | F / # | 景深 (µm) | Telecentricity (Degree) |
C C D | Mount |
|---|---|---|---|---|---|---|---|---|---|
| ITL-IDS-LT05X-65/D-5M | 0.5X | 65 | 8.4 | 0.04 | 6.25 | 1mm | 0.04 | 2/3"(11mm) | C |
| ITL-IDS-LT08X-65/D-5M | 0.8X | 65 | 5.2 | 0.064 | 6.25 | 391 | 0.02 | 2/3"(11mm) | C |
| ITL-IDS-LT10X-65/D-5M | 1.0X | 65 | 4.8 | 0.07 | 7.1 | 286 | 0.022 | 2/3"(11mm) | C |
| ITL-IDS-LT20X-65/D-5M | 2.0X | 65 | 2.8 | 0.12 | 8.3 | 83 | 0.03 | 2/3"(11mm) | C |
| ITL-IDS-LT20X-65/DI-5M | 2.0X | 65 | 2.8 | 0.12 | 8.3 | 83 | 0.03 | 2/3"(11mm) | C |
| ITL-IDS-LT30X-65/D-5M | 3.0X | 65 | 2.2 | 0.156 | 9.6 | 43 | 0.05 | 2/3"(11mm) | C |
| ITL-IDS-LT30X-65/DI-5M | 3.0X | 65 | 2.2 | 0.156 | 9.6 | 43 | 0.05 | 2/3"(11mm) | C |
| ITL-IDS-LT40X-65/D-5M | 4.0X | 65 | 2.1 | 0.16 | 12.5 | 31 | 0.02 | 2/3"(11mm) | C |
| ITL-IDS-LT40X-65/DI-5M | 4.0X | 65 | 2.1 | 0.16 | 12.5 | 31 | 0.02 | 2/3"(11mm) | C |
| ITL-IDS-LT03X-110/D-5M | 0.3X | 110 | 15.3 | 0.0219 | 6.9 | 3mm | 0.04 | 2/3"(11mm) | C |
| ITL-IDS-LT05X-110/D-5M | 0.5X | 110 | 7.2 | 0.0465 | 5.38 | 861 | 0.02 | 2/3"(11mm) | C |
| ITL-IDS-LT05X-110/DI-5M | 0.5X | 110 | 7.2 | 0.0465 | 5.38 | 861 | 0.02 | 2/3"(11mm) | C |
| ITL-IDS-LT07X-110/D-5M | 0.7X | 110 | 5.2 | 0.0651 | 5.38 | 439 | 0.02 | 2/3"(11mm) | C |
| ITL-IDS-LT07X-110/DI-5M | 0.7X | 110 | 5.2 | 0.0651 | 5.38 | 439 | 0.02 | 2/3"(11mm) | C |
| ITL-IDS-LT09X-110/D-5M | 0.9X | 110 | 4.5 | 0.075 | 6 | 296 | 0.025 | 2/3"(11mm) | C |
| ITL-IDS-LT10X-110/D-5M | 1.0X | 110 | 4.4 | 0.077 | 6.5 | 260 | 0.03 | 2/3"(11mm) | C |
| ITL-IDS-LT10X-110/DI-5M | 1.0X | 110 | 4.4 | 0.077 | 6.5 | 260 | 0.03 | 2/3"(11mm) | C |
| ITL-IDS-LT18X-110/D-5M | 1.8X | 110 | 4.1 | 0.081 | 11 | 136 | 0.03 | 2/3"(11mm) | C |
| ITL-IDS-LT20X-110/D-5M | 2.0X | 110 | 3.7 | 0.09 | 11 | 110 | 0.05 | 2/3"(11mm) | C |
| ITL-IDS-LT0315X-130I-5M | 0.315X | 130 | 13.3 | 0.0252 | 6.25 | 2.5 | 0.03 | 2/3"(11mm) | C |
| ITL-IDS-LT0348X-130I-5M | 0.348X | 130 | 12.1 | 0.0278 | 6.26 | 2 | 0.03 | 2/3"(11mm) | C |
| ITL-IDS-LT042X-132I-5M | 0.42X | 132 | 7.3 | 0.0462 | 4.5 | 1 | 0.03 | 2/3"(11mm) | C |
| ITL-IDS-LT07X-130I-5M | 0.7X | 130 | 5.3 | 0.063 | 5.5 | 449 | 0.03 | 2/3"(11mm) | C |
| ITL-IDS-LT017X-170I-5M | 0.17X | 170 | 19.7 | 0.017 | 5 | 6.9 | 0.03 | 2/3"(11mm) | C |
| ITL-IDS-LT026X-150I-5M | 0.26X | 150 | 13.7 | 0.0245 | 2.3 | 3.1 | 0.03 | 2/3"(11mm) | C |
| ITL-IDS-LT03X-170I-5M | 0.3X | 170 | 17.9 | 0.0187 | 8 | 3.5 | 0.03 | 2/3"(11mm) | C |
| ITL-IDS-LT065X-170/D-5M | 0.65X | 170 | 5.8 | 0.058 | 5.6 | 530 | 0.02 | 2/3"(11mm) | C |
| ITL-IDS-LT10X-150I-5M | 1.0X | 150 | 5.1 | 0.066 | 7.5 | 300 | 0.03 | 2/3"(11mm) | C |
| ITL-IDS-LT1.5X-150/D-5M | 1.5X | 150 | 4.4 | 0.075 | 10.0 | 177 | 0.03 | 2/3"(11mm) | C |
